Dettagli
QUESTO DISPOSITIVO PERMETTE DI SEPARARE L'AUDIO DA UNA QUALSIASI FONTE HDMI.
Features
- This adapter allows high resolution HD video (1080P) to feed through to the screen but adds the ability to channel the audio from the Chromecast to virtually any sound system.
- One HDMI input converted to one HDMI+ Audio ( SPDIF+R/L )output
- Input Resolution can up to 1080P(50/60Hz)
- HDMI to achieve the synchronization of audio signal separation.
There are PASS / 2.0CH / 5.1CH three kinds of audio mode options - LED indication when source or sink is working, LED relative to is light
- No loss of quality, Installs in minutes
Specifications
- HDMI Resolution: 24/50/60fs/1080p/1080i/720p/576p/576i/480p/480i
- Support Video Color Format: 24bit/deep color 30bit,36bit
- Audio Output: L/R+SPDIF
- Max Bandwidth: 225MHz
- Max Baud Rate: 6.75Gbps
- Input/Output TMDS Signal: 0.5~1.5Volts p-p(TTL)
- Input/Output DDC Signal: 5Volts p-p (TTL)
- Input Cable Distance: <=15m AWG26 HDMI standard cable
- Output Cable Distance: <=20m AWG26 HDMI standard cable
- Power Adapter Format: Input,AC (50HZ, 60HZ) 100V-240V; Output,DC 5V/1A
- Operating Temperature Range: -15 to +55 Degree C
- Operating Humidity Range: 5 to 90%RH (No Condensation)
- Size: 84 x 62 x 20 mm
- Weight: 145g
One Set Included
- 1 x HDMI to HDMI SPDIF+R/L Converter
- 1 x Power Adapter
